Aermacchi MB339-CB

NZ6464

MB339

Taken at Whenuapai, March 17, 2001. Forward cockpit - a general view from the port side. On the centrestand behind the control stick can be seen several advisory lights, the cabin altimeter, and the take control panels (TACAN, VOR, etc). The rudder pedal adjust is just visible in the centre. (See W01MAC56 for a description of the instrument panel and W01MAC55 for a description of the right console).
