Aermacchi MB339-CB

NZ6464

MB339

Taken at Whenuapai, March 17, 2001. HUD - seen from port exterior. The black of the HUD framing and forward coaming doesn't allow much contrast, but this gives an idea of the general arrangement. Note the two screens. Each screen is a two pieces glass composite. The display is projected seamlessly on the screens, allowing a larger display than just one screen. (Pretty nifty).
