Aermacchi MB339-CB

NZ6470

MB339

Taken at Whenuapai, March 17, 2001. Rear fuselage - port side looking forward. A number of panels are open - closest at the top contains a blow-off valve with the No1 battery beyond. the lower panel gives access to the weapons inventory panel, a circuit breaker panel, and the control units for the No1 and No2 generator.
